AZDEN FMX-22 2-Channel Portable Field Mixer
- 2 balanced XLR mic inputs and pan controls
- 2 balanced XLR outputs, Stereo mini-jack output for DSLR cameras and Headphone out with level control
Description
- 4x AA battery powered and Optional A/C adapter, Frequency Response: Main and Unbalanced Output: 20-20,000Hz (+0/-.5dB), Monitor Output: 50-17,000Hz (-3dB)
- Noise Level: Left & Right Channel: -119dBu (A weighted, Input Equivalent Level), T.H.D.: less than 0.005% @ 1KHz (+10dBu output), MIC Input Level: LO -21 dBu Gain +58dB max gain, HI -5dBu Gain +42dB max gain and Monitor Output: 3.5mm Stereo: -4dBu (32 ohm load) (Recommended load 16-100 ohms)
- Maximum Output Level: Balanced Output: , +15dBu (5K ohms), Unbalanced Output (3.5mm): -20dBu (2K ohms) and Battery Type/Duration: 4 – AA Alkaline – 15 hours
- Current Drain: 77mA nominal (Phantom Power Off), 118mA maximum (Phantom Power On), Phantom Power: Voltage: 48VDC (+/- 1.5VDC) and Dimensions: Size: 53.5H x 145W x 120D mm (2.19 x 5.70 x 4.75 inches), Weightwith o Battery: 23.58 ounces (670 grams)
- Switchable 48V phantom power and limiting and 5-step LED master bus
